cberg

Thanks @bcd I do try to search for things before posting. But I struggle with VW search function. Eventually, I did find this wish list thread... Interestingly no VW employee responded regarding why it was removed. I wonder if anybody at VW saw this.

VW 2023 used to have a look at Working Plane Shortcut/Button in the top toolbar. VW put this command behind a pulldown menu (alternately in the Right Click - Document Context Menu). Is there any way to get this back into the top toolbar? There are times when you really a one-click solution....

Does VW disappear or gray out? Sometimes the application grays out and appears when a pop up dialogue box is open somewhere, possibly off screen. It might appear that VW is not responding. if you are working on multiple monitors what happens when you unplug and gather all the windows to the primary computer display? Can you quit (as opposed to force quit) using command + w? if you haven’t already done so, you may want to turn off the confirm before auto save setting off. I vaguely remember having those sorts of issues a long time ago when I had that setting turned on.

Sigh... Service pack 6 and this bug has not been fixed.

That makes a lot of sense. Everything is built off the walls (as you would from a construction perspective). I like the idea of developing a interiors/finishes layer to help manage the 3d Information.

@GregG Very elegant models. I have a lot to learn design-wise. I am curious how you organize the model.... Regarding your file.... Do you do all solids modeling or do you use walls + whatever it takes? I like walls for a bunch of reasons, and I like them as parametric objects. However.... they don't play well with solid modeling. A few observations... Walls + Solids, for example, cannot be joined into an autohybrid; and autohybrids are hard to edit once made. If you add solids to the wall, then it becomes a nightmare to edit or move the wall. Wall features don't turn corners. Mouldings objects are already hybridized, so they dont join up with other solid objects. Do you put all the trim on classes or layers? C

I am interested in learning how folks organize architectural projects with lots of architectural woodwork and trim from a BIM perspective. I tend to build and class the walls, by construction phase—New, Existing, Demolition. The trim is then developed as a set of add-on features. I class woodwork according to whether it wants to be on or off in plan/RCP. (A_Trim Doors, Wall, Ceiling Trim, Base, etc). Ideally, walls would act as a container to help manage all this architectural detail. But for whatever reason, they do not. (Walls need some serious modernization.) I’m curious to know how others would tackle a project like this. The photo below describes the type of space I’m currently looking to document. @Paolo Your Mouldings Plugin is a must for this type of work... Thank you!

@Jonathan Pickup It takes a lot of effort to keep 2d plan/rcp sheets free and clear of 3d junk. Adding 3d detail can wreak havoc on plans or have unintended consequences elsewhere in a set. Going back through a set to make sure nothing was messed up is more tedious than switching out changed PDF sheets. (my opinion only).

Unfortunately version control is best managed at the PDF level not the BIM model. (For the reasons you describe.) Tedious as it may be, managing PDFs manually (option 2B) is the only failsafe solution. At the end of the day the primary deliverable is still the PDF drawing set. Archive your model after each release. So you can preserve the model at a given point in time.

Are there any answers to this question?

It looks like this was submitted as a wish list request in 2014, but it was probably not implemented.

Is there any way to show the slope dimension in fractions instead of decimals?

Thanks Pat. I think I've mostly gotten this to work.

10.5 years later.... Is there any way to control dashed hidden line thickness?

If you don't mind, I will send to you directly, because there is client sensitive info in the files. C.

Hi Pat, Thanks for looking at this. The same file backsaved into VW2023 generates a different worksheet result. How is is this possible? Assuming you are correct, entering .33 into my record field should result in 4"; however when I do this, the Record Format Length displays as 3/8".

I was struggling with worksheets this morning, and discovered a VW Worksheet glitch. VW 2024 makes an error when calculating lengths in a worksheet that is generated from a custom record. Document Units in both files are set to Feet and Inches. When I back saved the same file to VW2023 the error went away. In the first spreadsheet (VW2024) , a 4" Base Plate displays as 4'-0" (Not good!) You can see the record format shows the correct length, but the worksheet miscalculates the units. In the second spreadsheet (VW2023) the 4" Base Plate displays as 4" (Correct) Screenshot of the custom Record Format and worksheet at the bottom of page. Some more information about the custom Record Formats

Thank you. The problem also happens when you make Roof Faces. (Rectangles seem to be the culprit).

Thank you for the 67 New Toto Sanitary Fixtures. It makes a big difference getting useful VW Content. 😋

Looks like the VW window tool does this but Windoor does not? Interesting.

Is there a way to create this window in the Window/Windoor tool, or do I need to make a custom symbol? I guess the technical name of this shape is an arched single hung.

Thank you. @M5d and @Tom W.. Interestingly. VW2024 now includes an option for gap below leaf, which did not exist in VW2023. For whatever reason, I can manage Windoor for windows, but I absolutely can't deal with Windoor for doors. Something about that tool is profoundly counterintuitive at times.

Is there a way to set a keyboard command to activate the transform mode? (preferable to toggle). I know that U toggles between the different mode groups. But it would be nice to activate it directly somehow.

It drives me absolutely crazy that VW can't even draw an "X" in rough timber sections. This can't be a difficult feature to add to the framing member object. While we are at it, it is also mind-boggling that the wall framer command resorts to making geometry as 3D Solids instead of something parametric with top and bottom offset controls. Conceptually, framing as an overlay to the wall tool (which can be manipulated separately as needs arise but could be updated/ linked) makes a little more sense than trying to keep everything contained in the wall. To incrementally achieve fully framed walls, VW needs to develop a tool (or set of tools) that accomplishes framing. VW has a horizontal framing member but no vertical framing counterpart, which is inexplicable and tragic. The roadmap mentions "openings" as a new tool that will be developed, but the description is vague. Conceptually, openings could be a critical element in creating a framing vocabulary. (Horizontal members, Vertical Studs/Posts + Openings -- Think of the infinite BIM possibilities...) The mullion tool (which few people probably use) could form the basis for a "to be developed" Stud/Post Tool. The Stud/Post Tool should have a few profile shape options, like LG Metal Studs and 2 x sizes. There should be options for some connections and data regarding fasteners. Most importantly, the tool could integrate top/bottom offsets. Once developed, there should be a way to link the horizontal and vertical framing elements, like in the structural member tool. The problem is that VW is too "plan-focused," and all of this connection needs to happen in a vertical plane. Maybe create a wrapper of some sort to contain all the elements). Just some thoughts with only a half cup of coffee this morning.

Thank you both for the excellent suggestions. @BartHays I would need to go to VW remedial summer school (not a bad idea....) to be able to make something useful with Marionette. @VIRTUALENVIRONS, I will use your excellent model in the meantime. -C
