Hi All, I've reached the point where I'm trying to extract some 2D images from our first full 3D modelled project. I've done a bit of googling around but can't find any clear definitive advice about how to create 2D plans. Also it would be good to know any potential pitfalls or things to watch out for when modelling to achieve good 2D plan results.. As far as I can tell there are two options: 1- Make a viewport in the Traditional 2D way, as previously done when drawing in 2D. i.e. when creating a second floor plan, only the '2nd floor plan' layer would be turned on in the viewport. Any info from layers below (i.e. a ground floor roof, a Staircase drawn on the 1st Floor layer but which arrives at the 2nd floor plan) would have to be drawn on separately. Not ideal or very 'Smart' really, could end up with some inconsistencies. 2- Make a Section Cut viewport using either a) the section cut viewport tool, or b) using the clipping cube tool. The whole model would be turned on, so elements from below will appear. Care would have to be taken to get a good 'clipping' distance. Advantage is that it could show information from below, such as lower level roof structures or double height spacers. But this can include information you don't want to see sometimes. For instance, in a second floor plan I may see some outwards opening door swings from the ground floor plan below protruding out. Any advice from some of you seasoned 3D pros would be great! Thanks, A

I have been trying to create a model using cloud services so that my client can see proposals for a site. I have stripped back the vwx file as much as I can and when I upload the file to cloud services to create a vgx file, it just gives a blank screen (54.3 MB of blank screen). Can anyone help - Vectorworks UK support is closed for the holidays and I need to get this sorted by the time my client comes back from the Christmas break. I've attached the file and a link to the vgx file (cannot upload in here) https://cloud.vectorworks.net/links/11eb490c469a136a8fce0e8109945acd/ Albion - December 2020.vwx

I am experienced in VW2008 in 2D. I now have VW2016 Designer, and would like a one-to-one tutorial on creating 3d model from a survey of an old building. North London off Holloway Road. Happy to pay reasonable tuition fee. thank you

I have modeled and converted to a solid addition, and when I try taper solid, the tool fails. Why? File attached. Thanks tapersolid_notworking.vwx
