Seems my organization's server is blocking this. What is the website so that I can fix this with my IT people?

Door Type A-1 comes in 8-0, 7-6 and 7-0 heights. Why only one shows and how can I fix that? Thanks

If it is a 3D object you can decide it’s height AFF during its creation. (Drinking fountains, sinks, luminaires, etc). 2D symbols I’m not sure, but you certainly can move them in space up of down after you insert them in a drawing like another poster suggested.

Love data tags, but there’s a need to uniform how one works with them to get the auto-numbering benefit.

You can better during symbol creation raise it to the final AFF level you wish and it will insert accordingly.

Finally figured out. It had to do the the Manage Sequence Filter. You have to be careful that only the appropriate layer is selected. I had not selected the 2-Floor Layout and the numbering was operating on 1-Floor Layer also and you cannot have two doors with the same "Value", eg. 1-1 and 2-1 is not possible w/o the proper filter.

Thanks for the reply. The door should be 1-01 but entering the 01 in the ID Label box or the Door Schedule Worksheet will not work and the door number reverts to 03.

Hello, I have a styled door that will not accept "by instance" numbering (ID label). Why???

That small improvement can save lots of headaches bc all the other worksheets will update before printing final construction documents, but not that one. Thanks for the reply.

Thanks for the reply and sorry for the confusion. The "old one" (from Create Rm Finish Legend menu) does pick up legend items when placed in the drawing, but only the first time. As to suggestions... Can it be automated so that it reads the "keys" and descriptions from the Finish Schedule? Sometimes changes are made to the Room Finish Schedule and the Legend will not pick it up even if you use the "Recalculate" button because it is a Worksheet Image, I suppose.

How do you make yours? The old one is not reliable. Can it be automated so that it reads the "keys" from the Finish Schedule? Or do you use the Graphic Legends?

Thanks to all for the replies... finally found it!!! Not senile yet, but getting there. I don't remember turning it off.

Hi, I'm on 13.5 I'm a bit lost. What I'm trying to do is lock the snap to a distant corner.

Now when I approach a snappable object I get no hints.
